Name | Download |
---|---|
Catalog.pdf | Download |
Availability: | |
---|---|
| |
● Belt Friendly
Highly wear resistance, 5-7 times stronger
than steel roller
Self-lubricating, don't absorb water.
● Light Weight
Easy to carry;
Less power consumption, smaller motor
required.
● Excellent T.I.R
T.I.R ≤ 0.1mm.
● Zero Build-ups
No belt mis-tracking,less down time.
● Significantly improve the life of bearing
Designed Roller working life is 60,000hours.
● Patented Water & Dust Proof Sealing System
● Anti Corrosive & No Rust
● Belt Friendly
Highly wear resistance, 5-7 times stronger
than steel roller
Self-lubricating, don't absorb water.
● Light Weight
Easy to carry;
Less power consumption, smaller motor
required.
● Excellent T.I.R
T.I.R ≤ 0.1mm.
● Zero Build-ups
No belt mis-tracking,less down time.
● Significantly improve the life of bearing
Designed Roller working life is 60,000hours.
● Patented Water & Dust Proof Sealing System
● Anti Corrosive & No Rust
Keep Grease in Grease Leaking
Designed working life: 60,000hrs Designed working life: 30,000hrs
Highly Wear Resistance(Roller Failure Test) Easy to Wear When Roller Fails
◆ 5-7 times stronger than steel; ◆ Create shape point, tear the belt;
◆ Raise much lower temperature than steel. ◆ Raise high temperature, Causing Fire.
No "Pizza Cutter" Bearing Seat Break, Know as "Pizza Cutter"
◆ Bearing seat is locked in; ◆ Bearing Seat break from the welded point
◆ Belt friendly. and cut the belt.
Self-lubricating, No Belt Wear Belt Wear
◆ Low coefficient of friction; ◆ High coefficient of friction
◆ Belt friendly. ◆ Shorten belt service life .
Self-cleaning, No Material Buildups Material Buildups
◆ Don't absorb water; ◆ Absorb water;
◆ No belt mis-tracking, less down time. ◆ Cause belt mis-tracking, expensive labour cost.
Keep Grease in Grease Leaking
Designed working life: 60,000hrs Designed working life: 30,000hrs
Highly Wear Resistance(Roller Failure Test) Easy to Wear When Roller Fails
◆ 5-7 times stronger than steel; ◆ Create shape point, tear the belt;
◆ Raise much lower temperature than steel. ◆ Raise high temperature, Causing Fire.
No "Pizza Cutter" Bearing Seat Break, Know as "Pizza Cutter"
◆ Bearing seat is locked in; ◆ Bearing Seat break from the welded point
◆ Belt friendly. and cut the belt.
Self-lubricating, No Belt Wear Belt Wear
◆ Low coefficient of friction; ◆ High coefficient of friction
◆ Belt friendly. ◆ Shorten belt service life .
Self-cleaning, No Material Buildups Material Buildups
◆ Don't absorb water; ◆ Absorb water;
◆ No belt mis-tracking, less down time. ◆ Cause belt mis-tracking, expensive labour cost.
Superior Material:
Roller pipe are made of ultra high molecular weight polyethylene(UHMW-PE), an engineering plastic with a molecular weight of approximately 3 to 3,5 million g/mol, noise damping, highly wear resistance, self-lubricating.
Plus, with precise machining, it can significantly lower the TIR rate to 0.1mm or even less, dynamically balance to ISO1940-G16, lower the noise produced by vibration.
Patented Water & Dust Proof Sealing System:
1. Mutipal labyrinth + lip sealing system will prevent any contaminants such as dust, sludge, water etc, perfect for brutal working environment.
2. Using deep groove ball bearing.
Superior Material:
Roller pipe are made of ultra high molecular weight polyethylene(UHMW-PE), an engineering plastic with a molecular weight of approximately 3 to 3,5 million g/mol, noise damping, highly wear resistance, self-lubricating.
Plus, with precise machining, it can significantly lower the TIR rate to 0.1mm or even less, dynamically balance to ISO1940-G16, lower the noise produced by vibration.
Patented Water & Dust Proof Sealing System:
1. Mutipal labyrinth + lip sealing system will prevent any contaminants such as dust, sludge, water etc, perfect for brutal working environment.
2. Using deep groove ball bearing.
Standard: CEMA / JIS / DIN / ISO
Roller Diameters:
Φ63.5 | Φ76 | Φ89 | Φ102 |
Φ108 | Φ114 | Φ127 | Φ133 |
Φ140 | Φ152 | Φ159 | Φ165 |
Φ178 | Φ191 | Φ194 | Φ219 |
Roller Performance:
No. | Test items | Unit | Results |
1 | T. I.R | mm | ≤0.2 |
2 | Axial displacement | mm | ≤0.4 |
3 | Axial displacement after falling | mm | <1.2 |
4 | Axial load | KN | >1.5 |
5 | Rolling resistance | N | ≤2.5 |
6 | Water spay running test | g | 0 |
7 | Underwater running test | g | 5 |
8 | Coefficient of friction | - | ≤0.1 |
Standard: CEMA / JIS / DIN / ISO
Roller Diameters:
Φ63.5 | Φ76 | Φ89 | Φ102 |
Φ108 | Φ114 | Φ127 | Φ133 |
Φ140 | Φ152 | Φ159 | Φ165 |
Φ178 | Φ191 | Φ194 | Φ219 |
Roller Performance:
No. | Test items | Unit | Results |
1 | T. I.R | mm | ≤0.2 |
2 | Axial displacement | mm | ≤0.4 |
3 | Axial displacement after falling | mm | <1.2 |
4 | Axial load | KN | >1.5 |
5 | Rolling resistance | N | ≤2.5 |
6 | Water spay running test | g | 0 |
7 | Underwater running test | g | 5 |
8 | Coefficient of friction | - | ≤0.1 |
